HYDRAULIC VENEER SHEARING MACHINE
Model: MQJ310
The Hydraulic Veneer Shearing Machine is built for factories that need clean, consistent veneer cuts at production scale. Veneer cutting directly affects edge quality, material yield, and downstream pressing and lamination. A hydraulically driven blade gives smooth, controlled shearing force, so each cut leaves a tidy edge ready for the next stage. A motorised feeding system supports steady, repeatable operation across long production runs.
TECHNICAL PARAMETERS
| Component | Specification |
|---|---|
| Maximum cutting length | 3100mm |
| Maximum cutting width | 640mm |
| Maximum cutting thickness | 50mm |
| Hydraulic oil pump power | 4kW |
| Feeding motor power | 0.3kW |
| Maximum working pressure | 10mpa |
| Overall size | 4180 x 1680 x 1600mm |
| Net weight | 2850kg |
MAIN COMPONENTS
Heavy-duty machine frame
- Rigid structure that keeps the machine stable and the cut consistent under load
Hydraulic cylinder and shearing system
- Delivers the controlled cutting force, up to 10 MPa working pressure
Hydraulic power unit
- Supplies the pressure needed for the cutting stroke
Cutting blade assembly
- Shears veneer cleanly across the full 3100 mm cutting length
Motorised feeding system
- Moves material through the machine smoothly and consistently
Material table and support surface
- Moves material through the machine smoothly and consistently
Electrical control panel
- Controls machine operation and cutting cycles
Closer look of the machine
MACHINE GALLERY
HYDRAULIC VENEER SHEARING
Structure and Characteristics
Hydraulic Shearing Power
Smooth, controlled cutting force for consistent shearing across the full blade length.
Wide Working Area
Handles long veneer sheets in a single pass, cutting down on handling and joins in large-format work.
50 mm Cutting Thickness
Cuts veneer stacks up to 50 mm thick, so you can process several sheets per cycle.
640 mm Cutting Width
Takes wide veneer sheets for furniture panels, doors and cabinetry components.
Motorised Feeding System
A dedicated feeding motor supports steady material movement and repeatable results in production.
Robust Industrial Built
Machine built for stability and continuous factory use, with a rigid frame that supports cutting consistency.
